Fully Automatic Loop Handle Bag Maker With Continuous Sealers
Introduction
-
ModelLY-800LC
LY-800LC is a high-speed, specialized soft-loop bag making machine. The servo-driven feeding system works perfectly with soft-loop . The unique control of servo-feeding system with continuous sealer provides highly efficient and good quality of production. The human-machine interface is standard part for easy and friendly operation.
Features
- Specialized soft-loop bag making machine.
- High quality continuous sealing unit for top sealing.
- Servo-driven feeding system with one set of photocell for printed bag.
- Human-machine interface for easy setting.
SPECIFICATION
| Model | LY-800LC | ||
|---|---|---|---|
| Width | 270-650mm | ||
| Length | 250-650mm | ||
| Top Gusset | 70-75mm | ||
| Bottom Gusset | up to 75mm | ||
| Max. Production Speed Cycles / Min | 40-100 | ||
| Thickness of Film | 0.04-0.10mm | ||
| Heaters |
2.6KW x 1 0.3KW x 4 0.4KW x 4 |
||
| Power Required | 10KW | ||
| Machine dimensions | L | W | H |
| 7.4M | 2.1M | 2.32M | |
| Machine Weight | 3500Kg | ||
| Air compressor (Not included) | 10HP | ||
Notes：due to continual research and improvement, mechanical specifications are subject to further revision without prior notice.
Why Choose LY-800LC?
The LY-800LC is a high-speed automatic bag-making machine specifically designed for soft-loop bags. With its servo-driven feeding system, it maintains precise control even at high production volumes, making it ideal for large-scale manufacturing. It simplifies the operation process and enhances production efficiency.
