Fully Automatic Hot Slitting & Sealing Machine
Introduction
-
ModelLY-1200HS/LY-1600HS
LY-1200HS is a fully automatic, high speed hot slitting and sealing machine which converts sheet film into tubular film with good quality of sealing at the edge of film. It is suitable for full printing film.
Features
- Servo motor for rewinding unit.
- Line position control.
- Auto-tension control for unwinding stand.
- Auto-tension control for rewinding stand.
- Edge trimming and waste collecting unit.
SPECIFICATION
| Model | LY-1200HS | LY-1600HS | ||||
|---|---|---|---|---|---|---|
| Max.Film Width | 1200 mm | 1600 mm | ||||
| Film Thickness | 0.03-0.1 mm | 0.03-0.1 mm | ||||
| Max Production | up to 180 M/per min | up to 180 M/per min | ||||
| Material | LLDPE, LDPE, HDPE, CPP | LLDPE, LDPE, HDPE, CPP | ||||
| Max. Reel Dia. | 700 mm | 700 mm | ||||
| Max. Reel Weight | 200kgs | 200kgs | ||||
| Power Required | 7 kw | 7 kw | ||||
| Machine dimensions | L | W | H | L | W | H |
| 4.5M | 2.5M | 1.6M | 5.0M | 2.65M | 1.6M | |
| Machine Weight | 1300kg | 1500kg | ||||
Notes：due to continual research and improvement, mechanical specifications are subject to further revision without prior notice.
Why Choose Fully Automatic Hot Slitting & Sealing Machine?
The LY-1200HS is a fully automatic high-speed hot slitting and sealing machine that converts sheet film into tubular film with high-quality edge sealing. It is suitable for full printing films. Featuring a servo-driven rewinding unit and auto-tension control for both unwinding and rewinding stands, it ensures stable and efficient production.
